Description

PUMP UNIT SPECIFICATIONS

• C.E.T. single stage centrifugal pump
• Pump body made from high resistance aluminum alloy
• Bronze impeller
• Mechanical shaft seal
• Electric priming system guaranteed up to 20’ (6 meters) lift
• Two 2 1⁄2’’ (65 mm) delivery outlet with a pressure valve
• One 4’’ (100 mm) suction inlet
• Dimensions: Length: 41 1⁄4’’ (1047 mm); Width: 31 5/8’’ (803 mm); Height: 31 1⁄2’’ (800 mm)
• Weight: 530 lbs (241 kg)

ENGINE SPECIFICATIONS

• Rebuilt Volkswagen 46hp at 3600 RPM, air cooled engine
• 4-cylinder, 4-stroke gasoline engine
• Electric start
• Three gallons (11,4L) capacity remote fuel tank

INCLUDED ACCESSORIES

• 14 Amps alternator
• Vernier throttle
• 12-V Battery
• Low oil alert
• Pressure gauge
